COATED FABRICS
Coated Fabrics:
Material |
Coating |
Operating Temperature |
Data Sheets |
| 1700 | Silicone rubber coated | Base fabric: 1000°F Coating: 500°F | Data Sheet |
| 3200 | Silicone rubber coated | Base fabric: 1000°F Coating: 500°F | Data Sheet |
| GR2-SRC | Silicone rubber coated one side | Base fabric: 1000°F Coating: 500°F | Data Sheet |
| 1400V | Vermiculite coated | 1,800°F | Data Sheet |
| 1800 | Vermiculite coated | 1,800°F | Data Sheet |
| 3600 | Vermiculite coated | 1,800°F | Data Sheet |
| HB32 | Vermiculite coated | 1,900°F | Data Sheet |
| 2025AL | Aluminized coated, one side | 350/1,000°F | Data Sheet |
| BB Board | Aluminized coated, one side | 1000/1,800°F | Data Sheet |
| PTFE | Teflon coated | 600°F | Data Sheet |
| 2523S | Acrylic coated/Salmon color | 300°F | Data Sheet |
| 2800 E | Acrylic coated/Yellow color | 1000°F | Data Sheet |
| 2200 Kevlar | Coated aramid fiber blend | 600°F | Data Sheet |
17oz. Silicone Rubber Coated Fiberglass
-
Water, oil and abrasion resistant. Lightweight and easy to sew or cut.
Flange and valve covers
Removable insulation blankets, sleeves, insulation pads
Welding blankets
Welding curtains
About the Fabric |
|
| Weave | Satin |
| Coating | Impregnated flame resistant silicone rubber coating |
| Color | Various |
| Width (Typical) | 60" |
| Weight | 17oz./yd² +/- 1.5oz. |
| Thickness | .017" +/- .0015" |
| Temperature Range | -70°F to 1000°F (base fabric 1000°F/coating 500°F) |
| Tensile Strength | Warp: 300lbs./in. min. Fill: 250lbs./in. min. |
| Tear Strength | Warp: 50lbs./in. min. Fill: 40lbs./in. min. |
| Flame Resistance | Flame out: 1 sec Afterglow: 1 sec Char length: 0.5" |
32oz. Silicone Rubber Coated Fiberglass
-
Flange covers
Removable insulation covers
Equipment covers
Protective sleeves for cable and coils
Spatter protection
Misc. equipment covers
About the Fabric |
|
| Weave | Satin |
| Coating | Impregnated flame resistant silicone rubber coating |
| Color | Various |
| Width (Typical) | 60" |
| Weight | 32oz./yd² +/- 3oz. |
| Thickness | 0.032" +/- .003" |
| Temperature Range | -70°F to 1000°F (base fabric 1000°F/coating 500°F) |
| Tensile Strength | Warp: 400lbs./in. min. Fill: 350lbs./in. min. |
| Flame Resistance | Flame out: 1 sec Afterglow: 1 sec Char length: 0.5" |
GR2-SRC Fiberglass Fabric/One Sided Coated Gray
-
Welding blankets
Expansion joints
Protective sleeves & covers
Flange covers
Removable insulation blankets
About the Fabric |
|
| Weave | Twill |
| Coating | Fiberglass fabric with a special, high temperature silver silicone coating on one side (gray) |
| Base Fabric Weight | 36oz./yd² +/- 10% |
| Weight with Coating | 45oz./yd² +/- 10%. |
| Thickness | .05" +/- 10% |
| Temperature Resistance | Base fabric: 1000°F (Silicone coating: 500%) |
1400V
(Vermiculite Coated Silica Fabric)
-
Industrial blankets
Fire blankets and curtains
Heat shields and torch guards
Expansion joints
Protection from molten metal splashes and sparks
Welding blankets
Kneeling pads
About the Fabric |
|
| Weave | Plain |
| Coating | Vermiculite |
| Color | Tan |
| Width | 36" |
| Mass-Area Ratio | 1400 g/m² +/- 140 g/m² |
| Thickness | 1.4mm |
| Temperature Resistance | 1800°F Steady State |
| Content of Main Components | SIO2: 98.0% +/- 1.0% |
| Yarn Count (cm) | Warp: 12cm + 1cm Weft: 6cm +/- 1cm |
1800
(Vermiculite Coated Silica Fabric)
-
Insulation pads and blankets
Fire blankets
Welding blankets
Slow cool covers
Welding curtains fire blanket
About the Fabric |
|
| Weave | Satin |
| Coating | Vermiculite |
| Color | Tan |
| Weight | 18oz/yd² +/- 10% oz/yd² |
| Width | 36" |
| Thickness | 0.028" +/- 10% |
| Temperature Resistance | Steady State: 1800°F Melting Temp: 3000°F |
| Content of Main Components | SIO2: 95.0% +/- 1.0% |
| Tensile Strength (lb./in.) | Warp: 560lb./in. Weft: 350lb./in. |
3600
(Vermiculite Coated Silica Fabric)
-
Insulation pads and blankets
Valve covers
Fire blankets
Curtain material
Heat shields
Welding curtains
Scaffold protection
Fire blanket generator covers
Slow cool covers
About the Fabric |
|
| Weave | Satin |
| Coating | Vermiculite |
| Color | Tan |
| Mass per unit area (oz/yd²) | 36oz/yd² +/- 0.902oz/yd² |
| Thickness | 0.031in +/- 0.003in |
| Temperature Resistance | Steady State: 1800°F |
| Content of Main Components | SIO2: 95.0% +/- 1.0%, |
| Thread Count | Warp: 48.3 in +/- 2.5 in Weft: 35.6 in +/- 2.5in |
| Tensile strength (lbs./in) | Warp: 319.8lbs./in. Weft: 217lbs./in. |
| Mass per unit area (oz/yd²) | 36oz/yd² +/- 0.902oz/yd² |
HB32
(Vermiculite Coated Silica Fabric)
-
Welding and furnace curtains
Insulation blankets
Gaskets
PWHT and slow cool blankets, wraps, etc.
About the Fabric |
|
| Weave | Broken twill |
| Coating | Vermiculite |
| Color | Tan |
| Width | 60" |
| Thickness | 0.045in. |
| Weight | 32oz/yd² |
| Temperature Resistance | Steady State: 1900°F Melting Temp: 3000°F |
| Tensile Strength | Warp: 610lbs. Weft: 346lbs. |
| Content of Main Components | SIO2: > 95.0% |
| Thread Count | Warp: 45.7" +/- 2.5" Weft: 25.4" +/- 2.5" in" |
2025 Fiberglass
Aluminized One Side
-
Flange covers
Reflective curtains and shields
Tadpole seals
Heat shields
Protective sleeves
About the Fabric |
|
| Weave | Plain Weave Fiberglass |
| Coating | Aluminized one side coating |
| Color | One side aluminized, one side tan |
| Weight | 19.5oz./yd² +/- 10% |
| Thickness | 0.026" +/- 10% |
| Temperature Resistance | Aluminized face: 300°F to 350°F Base fabric: 1000°F |
| Burst Strength | 550psi |
| Tensile Strength | Warp: 250lbs./in.Fill: 250lbs./in. |
| Tear Strength | Warp: 50lbs.Fill: 50lbs. |
| Flame Resistance | Flame out: 1 sec max Afterglow: 1 sec max Char length: 1" max |
BB Board
Aluminized One Side
-
Designed to insulate and conform to most shapes to reflect heat.
Covers for flanges and valve equipment
Oven liners
Door seals
Slow cool blankets
Pipe wrap
Die cutting pieces
HVAC wrap
Appliance insulation
About the Fabric |
|
| Weave | Silica needled mat (SNM) insulation with aluminum coating |
| Color | Mat is white; Aluminized face is silver |
| Coating | One side aluminized |
| Content of Main Components | SIO2: 98.0% |
| Temperature Resistance | Aluminized Face: 1000°F Silica Side: 1800°F |
| Roll Size | 36" x 65"; Sheets available |
| Thickness | 1/2" |
PTFE Fiberglass
(Teflon Coated)
-
Removable insulation covers
Weather and chemical barrier blankets
Protective sleeves
Insulation pads
Welding pads
Flange covers
About the Fabric |
|
| Weave | Satin |
| Coating | Fiberglass fabric with a fluorocarbon (Teflon) coating |
| Color | One side black, one side gold |
| Width (Typical) | 60" |
| Weight | 16.5oz./yd² +/- 10% |
| Thickness | 0.015" +/- 10% |
| Temperature Resistance | -67°F to 600°F |
| Tensile Strength | Warp: 400lbs./in.Fill: 300lbs./in. |
| Trapezoidal Tear | Warp: 50lbs.Fill: 30lbs. |
| Flame Resistance | Flame out: 1 sec max Afterglow: 1 sec max Char length: 1" max |
2523 Fiberglass
(Acrylic Coating)
-
Welding curtains
Arc flash barriers
Fire retardant weather barrier material
Grinding shields
Areas that require high visibility for safety and resistance to sparks, abrasion, water and most chemicals
About the Fabric |
|
| Weave | Plain |
| Color | Salmon |
| Weight | 16.5oz./yd² +/- 10% |
| Thickness | .016" +/- 10% |
| Temperature Resistance | 0°F to 300°F |
| Burst Strength | 475psi |
| Tensile Strength | Warp: 300lbs./in. Fill: 250lbs./in. |
| Tear Strength | Warp: 35lbs. Fill: 30lbs. |
| Flame Resistance | Flame out: 0 sec max Afterglow: 1 sec max Char length: 1" max |
2800 E Fiberglass
(Acrylic Coating)
-
Vertical welding curtains for spark containment
Flash barriers
Heat shields
Fabric and fire resistant coating are specifically designed to resist slag, sparks, and incidental flame from cutting torches
About the Fabric |
|
| Weave | Plain |
| Coating | Heavy weight fabric with yellow acrylic coating |
| Color | Yellow |
| Weight | 28oz./y² +/- 10% |
| Temperature Resistance | Coating: -40°F to 300°F Base Fabric: 1000°F |
| Burst Strength | 670psi |
| Tensile Strength | Warp: 425lbs./in. Fill: 354lbs./in. |
| Tear Strength | Warp: 108lbs. Fill: 118lbs. |
| Flame Resistance | Flame out: 1 sec max Afterglow: 6 sec max Char length: 1/16" max |
2200 Kevlar
(Aramid Fiber Blend)
-
Protective sleeves
Heat shields and protective curtains
Tadpole seals
Misc. equipment covers
About the Fabric |
|
| Weave | Aramid fiber blend |
| Color | Yellow |
| Weight | 22oz./y² +/- 10% |
| Thickness | 0.08in +/- 0.001in |
| Temperature Resistance | 600°F |
| Count | 20 x 11 |
| Tensile Strength | Warp: 225lbs./in.Fill: 150 ends/in. |
